Image is for reference only.

TE Connectivity 2328702-8

Manufacturer Part #:

2328702-8

Manufacturer:

TE Connectivity

Package/Case:

SMD,P=0.5mm,Surface Mount，Right Angle

Datasheet:

2328702-8

Description:

Flip type -40℃~+85℃ 8P Dual-sided contacts / top and bottom connection Horizontal attachment 0.5mm SMD,P=0.5mm,Surface Mount，Right Angle FFC, FPC (Flat Flexible) Connector Assemblies ROHS

Loading…

Specifications

Product Details

Type	Description	Select
Category	FFC, FPC (Flat Flexible) Connector Assemblies
Manufacturer	TE Connectivity
Package/Case	SMD,P=0.5mm,Surface Mount，Right Angle
Operating Temperature	-40℃~+85℃
Locking Feature	Flip type
Contact Plating	Gold
Pitch	0.5mm
Contact Material	Copper alloy
Contact Type	Dual-sided contacts / top and bottom connection
Number of Contacts	8P
Height Above Board	1.05mm
Mounting Type	Horizontal attachment
FFC, FCB Thickness	0.3mm
