Image is for reference only.

JST B2B-XH-A(LF)(SN)

Manufacturer Part #:

B2B-XH-A(LF)(SN)

Manufacturer:

JST

Package/Case:

Plugin,P=2.5mm

Datasheet:

B2B-XH-A(LF)(SN)

Description:

1x2P 2P XH Tin 2 -25℃~+85℃ 3A 1 2.5mm Brass Direct Insert Plugin,P=2.5mm Wire To Board Connector ROHS

Loading…

Specifications

Product Details

Type	Description	Select
Category	Wire To Board Connector
Manufacturer	JST
Package/Case	Plugin,P=2.5mm
Operating Temperature	-25℃~+85℃
Number of Rows	1
Voltage Rating	250V
Color	White
Current Rating	3A
Row Spacing	-
Pins Structure	1x2P
Mounting Type	Direct Insert
Flame Retardant Rating	UL94V-0
Y-Width of Bottom Edge on Board	5.75mm
Reference Series	XH
X-Length of Bottom Edge on Board (Spacing Line)	7.4mm
Contact Plating	Tin
Pitch	2.5mm
Number of Pins	2P
Contact Material	Brass
Supplementary Features	K-leg punch
Plastic Material	PA66
Z-Height of the Board	7mm
Number of PINs Per Row	2
