Image is for reference only.

UMW(Youtai Semiconductor Co., Ltd.) UC3842B

Manufacturer Part #:

UC3842B

Manufacturer:

UMW(Youtai Semiconductor Co., Ltd.)

Package/Case:

SOP-8

Datasheet:

UC3842B

Description:

1A 47kHz~57kHz 16V~30V SOP-8 AC-DC Controllers and Regulators ROHS

Loading…

Specifications

Product Details

Type	Description	Select
Category	AC-DC Controllers and Regulators
Manufacturer	UMW(Youtai Semiconductor Co., Ltd.)
Package/Case	SOP-8
Operating Temperature	0℃~+70℃
Frequency - Switching	47kHz~57kHz
Voltage - Supply	16V~30V
Output Current	1A
Duty Cycle(Max)	100%
Isolation	Non-isolated
Features	Overvoltage Protection (OVP);Short-Circuit Protection(SCP);Thermal Protection;Overcurrent Protection(OCP);Undervoltage Protection(UVP);Soft Start
Topology	Step-down;Boost
Voltage - Breakdown	-
Pd - Power Dissipation	1W
